TRINAMIC Motion Control GmbH
| Part Number | PD42-1-1270-CANOPEN | Manufacturer | TRINAMIC Motion Control GmbH |
|---|---|---|---|
| Description | PANDRIVE NEMA17, 24V, 38 OZ IN/ | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 693 pcs | Data sheet | 1.PD42-1-1270-CANOPEN.pdf2.PD42-1-1270-CANOPEN.pdf3.PD42-1-1270-CANOPEN.pdf |
| Weight | 0.485 lb (219.99g) | Voltage - Rated | 24VDC |
| Type | Hybrid | Torque - Holding (oz-in / mNm) | 31.2 / 220 |
| Termination Style | Connector | Steps per Revolution | 200 |
| Step Angle | 1.8° | Size / Dimension | Square - 1.654" x 1.654" (42.00mm x 42.00mm) |
| Series | PANdrive™ | Rotor Inertia | 35gcm² |
| Other Names | 1460-1205 30-0300 |
Operating Temperature | -20°C ~ 50°C |
| NEMA Frame Size | 17 | Mounting Hole Spacing | 1.220" (31.00mm) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Length - Shaft and Bearing | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Integrated Controller, Round Shaft | Diameter - Shaft | - |
| Detailed Description | Bipolar Stepper Motor Hybrid Frame Size 17 200 Step 1A 24VDC | Current Rating | 1A |
| Coil Type | Bipolar | Coil Resistance | 1 Ohms |
| Approvals | - | Accuracy | ±5% |
