Toshiba Semiconductor and Storage
| Part Number | TLP624-4(F) | Manufacturer | Toshiba Semiconductor and Storage |
|---|---|---|---|
| Description | OPTOISOLTR 5KV 4CH TRANS 16-DIP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5981 pcs | Data sheet | TLP624-4(F).pdf |
| Voltage - Output (Max) | 55V | Voltage - Isolation | 5000Vrms |
| Voltage - Forward (Vf) (Typ) | 1.15V | Vce Saturation (Max) | 400mV |
| Turn On / Turn Off Time (Typ) | 10µs, 8µs | Supplier Device Package | 16-DIP |
| Series | - | Rise / Fall Time (Typ) | 8µs, 8µs |
| Packaging | Tube | Package / Case | 16-DIP (0.300", 7.62mm) |
| Output Type | Transistor | Other Names | TLP624-4 (F) TLP624-4F TLP6244F |
| Operating Temperature | -55°C ~ 100°C | Number of Channels | 4 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Type | DC |
| Detailed Description | Optoisolator Transistor Output 5000Vrms 4 Channel 16-DIP | Current Transfer Ratio (Min) | 100% @ 1mA |
| Current Transfer Ratio (Max) | 1200% @ 1mA | Current - Output / Channel | 50mA |
| Current - DC Forward (If) (Max) | 50mA |
