Sullins Connector Solutions
| Part Number | GEC05DAAN | Manufacturer | Sullins Connector Solutions |
|---|---|---|---|
| Description | CONN HDR VERT 10POS .100" TIN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 107060 pcs | Data sheet | 1.GEC05DAAN.pdf2.GEC05DAAN.pdf3.GEC05DAAN.pdf |
| Voltage - DC Spark Over (Nom) | Phosphor Bronze | Type Attributes | - |
| Termination | Solder | Style | Board to Board or Cable |
| Stacking Direction | Male Pin | Shrouding | 0.100" (2.54mm) |
| Shield Termination | Square | Series | - |
| Row Spacing - Mating | Unshrouded | RoHS Status | Bulk |
| Ripple Current - Low Frequency | - | Pitch - Connector | - |
| Overall Contact Length | 0.120" (3.05mm) | Operating Temperature | -65°C ~ 150°C |
| Number of Rows | 2 | Number of Positions | 10 |
| Number of Contacts | 100µin (2.54µm) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Material - Insulation | All | Manufacturer Standard Lead Time | 3 Weeks |
| Manufacturer Part Number | GEC05DAAN | Length - Post (Mating) | - |
| Insulation Material | Tin | Insulation Height | 0.450" (11.43mm) |
| Features | - | Expanded Description | 10 Positions Header, Breakaway Connector 0.100" (2.54mm) Through Hole Tin |
| Description | CONN HDR VERT 10POS .100" TIN | Current Rating | 3A |
| Current - Max/Contact | - | Contact Length - Post | 0.230" (5.84mm) |
| Contact Length - Mating | 0.100" (2.54mm) | Contact Finish Thickness - Post | Polyamide (PA9T), Nylon 9T |
| Contact Finish Thickness - Mating | Tin | Contact Finish - Post | 100µin (2.54µm) |
| Contact Finish - Mating | 0.100" (2.54mm) | Connector Type | Header, Breakaway |
| Actual Diameter | Black |
