Panasonic
| Part Number | PA1A-5V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GENERAL PURPOSE SPST 5A 5V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4640 pcs | Data sheet | PA1A-5V.pdf |
| Turn On Voltage (Max) | 3.5 VDC | Turn Off Voltage (Min) | 0.25 VDC |
| Termination Style | PC Pin | Switching Voltage | 250VAC, 110VDC - Max |
| Series | PA | Release Time | 5ms |
| Relay Type | General Purpose | Packaging | Tube |
| Other Names | 255-1738 255-1738-5 255-1738-ND PA1A5V |
Operating Temperature | -40°C ~ 70°C |
| Operate Time | 10ms | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Sealed - Fully | Detailed Description | General Purpose Relay SPST-NO (1 Form A) 5VDC Coil Through Hole |
| Contact Rating (Current) | 5A | Contact Material | Silver Nickel (AgNi) |
| Contact Form | SPST-NO (1 Form A) | Coil Voltage | 5VDC |
| Coil Type | Non Latching | Coil Resistance | 208 Ohms |
| Coil Power | 120 mW | Coil Current | 24.0mA |
