Orion Fans
| Part Number | OD9225-24HB01A | Manufacturer | Orion Fans |
|---|---|---|---|
| Description | FAN AXIAL 92.5X25MM 24VDC WIRE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10288 pcs | Data sheet | 1.OD9225-24HB01A.pdf2.OD9225-24HB01A.pdf3.OD9225-24HB01A.pdf4.OD9225-24HB01A.pdf5.OD9225-24HB01A.pdf |
| Width | 25.00mm | Weight | - |
| Voltage Range | 12 ~ 28VDC | Voltage - Rated | 24VDC |
| Termination | 3 Wire Leads | Static Pressure | 0.130 in H2O (32.4 Pa) |
| Size / Dimension | Square - 92.5mm L x 92.5mm H | Series | OD9225 |
| RPM | 2900 RPM | Other Names | 1053-1282 OD9225-24HB01AX OD922524HB01A |
| Operating Temperature | -4 ~ 176°F (-20 ~ 80°C) | Noise | 35.0 dB |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced | Manufacturer Standard Lead Time | 19 Weeks |
| Lifetime @ Temp. | 60000 Hrs @ 40°C | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Features | Speed Sensor (Tach) |
| Fan Type | Tubeaxial | Current Rating | 0.150A |
| Bearing Type | Ball | Approvals | cURus, TUV |
| Air Flow | 53.0 CFM (1.48m³/min) |
