NZ2520SHA-60M-END5301A

NDK

Image may be representation. See specifications for product details.

Product Overview

Part Number:	NZ2520SHA-60M-END5301A
Manufacturer/Brand:	NDK
Product description	OSC 60MHZ CMOS SMD
Datasheets:	NZ2520SHA-60M-END5301A.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	74910 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 74910 pcs

Reference Price (In US Dollars)

1 pcs: $0.661

10 pcs: $0.631

50 pcs: $0.616

100 pcs: $0.528

500 pcs: $0.513

1000 pcs: $0.433

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.661

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of NZ2520SHA-60M-END5301A

Part Number	NZ2520SHA-60M-END5301A	Manufacturer	NDK
Description	OSC 60MHZ CMOS SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	74910 pcs	Data sheet	NZ2520SHA-60M-END5301A.pdf
Voltage - Supply	1.8 ~ 3.3V	Type	XO (Standard)
Size / Dimension	0.098" L x 0.079" W (2.50mm x 2.00mm)	Series	NZ2520SHA
Ratings	AEC-Q100, AEC-Q200	Packaging	Cut Tape (CT)
Package / Case	1008 (2520 Metric), 4 PC Pad	Output	CMOS
Other Names	644-1285-1	Operating Temperature	-40°C ~ 125°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	12 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height - Seated (Max)	0.035" (0.90mm)	Function	Standby (Power Down)
Frequency Stability	±100ppm	Frequency	60MHz
Detailed Description	60MHz XO (Standard) CMOS Oscillator 1.8 ~ 3.3V Standby (Power Down) 1008 (2520 Metric), 4 PC Pad	Current - Supply (Max)	9mA
Current - Supply (Disable) (Max)	-	Base Resonator	Crystal
Absolute Pull Range (APR)	-
