Mill-Max
| Part Number | 871-43-021-20-001000 | Manufacturer | Mill-Max |
|---|---|---|---|
| Description | RIGHT ANGLE SHRINK-DIP SOCKET 21 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 19008 pcs | Data sheet | 1.871-43-021-20-001000.pdf2.871-43-021-20-001000.pdf |
| Voltage Rating | - | Termination | Solder |
| Style | Board to Board | Series | 871 |
| Row Spacing - Mating | - | Pitch - Mating | 0.070" (1.78mm) |
| Packaging | Tube | Other Names | 8.7143E+15 ED1052 |
| Operating Temperature | -55°C ~ 125°C | Number of Rows | 1 |
| Number of Positions Loaded | All | Number of Positions | 21 |
| Mounting Type | Through Hole, Right Angle | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | - |
| Manufacturer Standard Lead Time | 4 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polycyclohexylenedimethylene Terephthalate (PCT), Polyester | Insulation Height | 0.104" (2.64mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | - | Fastening Type | Push-Pull |
| Detailed Description | 21 Position Receptacle Connector 0.070" (1.78mm) Through Hole, Right Angle Gold | Current Rating | 3A |
| Contact Type | Female Socket | Contact Shape | Circular |
| Contact Material | Beryllium Copper | Contact Length - Post | 0.122" (3.10mm) |
| Contact Finish Thickness - Post | 200.0µin (5.08µm) | Contact Finish Thickness - Mating | 30.0µin (0.76µm) |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold |
| Connector Type | Receptacle | Applications | - |
