Keystone Electronics Corp.
| Part Number | 8722 | Manufacturer | Keystone Electronics Corp. |
|---|---|---|---|
| Description | TERM BLOCK PLUG 2POS 90DEG 3.5MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 83669 pcs | Data sheet | 8722.pdf |
| Wire Strip Length | - | Wire Gauge or Range - mm² | - |
| Wire Gauge or Range - AWG | 16-22 AWG | Voltage - UL | 250V |
| Type | Plug for Unshrouded Header | Torque - Screw | - |
| Termination Style | Screw - Leaf Spring, Wire Guard | Series | - |
| Screw Size | - | Positions Per Level | 2 |
| Plug Wire Entry | 90° | Pitch | 0.138" (3.50mm) |
| Packaging | Bulk | Other Names | 36-8722 8722K 8722K-ND |
| Operating Temperature | -30°C ~ 120°C | Number of Positions | 2 |
| Number of Levels | 1 | Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Height | 0.394" (10.00mm) | Ingress Protection | - |
| Housing Material | Polybutylene Terephthalate (PBT) | Header Orientation | - |
| Features | Interlocking (Side) | Detailed Description | 2 Position Terminal Block Plug for Unshrouded Header 0.138" (3.50mm) 90° Free Hanging (In-Line) |
| Current - UL | 6A | Current - IEC | - |
| Contact Tail Length | - | Contact Mating Finish | Tin |
| Contact Material | Brass | Color | Blue |
