International Rectifier (Infineon Technologies)
| Part Number | IRF6706S2TR1PBF | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | MOSFET N-CH 25V 17A DIRECTFET-S1 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 61169 pcs | Data sheet | IRF6706S2TR1PBF.pdf |
| Vgs(th) (Max) @ Id | 2.35V @ 25µA | Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) | Supplier Device Package | DIRECTFET S1 |
| Series | HEXFET® | Rds On (Max) @ Id, Vgs | 3.8 mOhm @ 17A, 10V |
| Power Dissipation (Max) | 1.8W (Ta), 26W (Tc) | Packaging | Original-Reel® |
| Package / Case | DirectFET™ Isometric S1 | Other Names | IRF6706S2TR1PBFDKR |
| Operating Temperature | -55°C ~ 175°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 1810pF @ 13V | Gate Charge (Qg) (Max) @ Vgs | 20nC @ 4.5V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V | Drain to Source Voltage (Vdss) | 25V |
| Detailed Description | N-Channel 25V 17A (Ta), 63A (Tc) 1.8W (Ta), 26W (Tc) Surface Mount DIRECTFET S1 | Current - Continuous Drain (Id) @ 25°C | 17A (Ta), 63A (Tc) |
