Hamlin / Littelfuse
| Part Number | SMDH160-2 | Manufacturer | Hamlin / Littelfuse |
|---|---|---|---|
| Description | PTC RESET FUSE 16V 1.6A 2SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 133234 pcs | Data sheet | 1.SMDH160-2.pdf2.SMDH160-2.pdf |
| Voltage - Max | 16V | Type | Polymeric |
| Time to Trip | 15s | Thickness (Max) | 0.118" (3.00mm) |
| Size / Dimension | 0.343" L x 0.250" W (8.70mm x 6.36mm) | Series | PolySwitch®, SMD |
| Resistance - Post Trip (R1) (Max) | 150 mOhms | Resistance - Initial (Ri) (Min) | 50 mOhms |
| Ratings | - | Packaging | Cut Tape (CT) |
| Package / Case | 2-SMD | Other Names | F7705CT F7705CT-ND SMDH160-2CT |
| Operating Temperature | -40°C ~ 125°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 2A (4 Weeks) | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Spacing | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height - Seated (Max) | - | Detailed Description | Polymeric PTC Resettable Fuse 16V 1.6A Ih Surface Mount 2-SMD |
| Current - Trip (It) | 3.2A | Current - Max | 70A |
| Current - Hold (Ih) (Max) | 1.6A | Approvals | CSA, TUV, UL |
