Electro-Films (EFI) / Vishay
| Part Number | SI7190ADP-T1-RE3 | Manufacturer | Electro-Films (EFI) / Vishay |
|---|---|---|---|
| Description | MOSFET N-CHAN 250V POWERPAK SO-8 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 92528 pcs | Data sheet | SI7190ADP-T1-RE3.pdf |
| Vgs(th) (Max) @ Id | 4V @ 250µA | Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) | Supplier Device Package | PowerPAK® SO-8 |
| Series | ThunderFET® | Rds On (Max) @ Id, Vgs | 102 mOhm @ 4.3A, 10V |
| Power Dissipation (Max) | 5W (Ta), 56.8W (Tc) | Packaging | Cut Tape (CT) |
| Package / Case | PowerPAK® SO-8 | Other Names | SI7190ADP-T1-RE3CT |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 860pF @ 100V | Gate Charge (Qg) (Max) @ Vgs | 22.4nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 7.5V, 10V | Drain to Source Voltage (Vdss) | 250V |
| Detailed Description | N-Channel 250V 4.3A (Ta), 14.4A (Tc) 5W (Ta), 56.8W (Tc) Surface Mount PowerPAK® SO-8 | Current - Continuous Drain (Id) @ 25°C | 4.3A (Ta), 14.4A (Tc) |
