HCPL-314J-000E

Avago Technologies (Broadcom Limited)

Image may be representation. See specifications for product details.

Product Overview

Part Number:	HCPL-314J-000E
Manufacturer/Brand:	Avago Technologies (Broadcom Limited)
Product description	OPTOISO 5KV 2CH GATE DRIVER 16SO
Datasheets:	HCPL-314J-000E.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	57708 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 57708 pcs

Reference Price (In US Dollars)

1 pcs: $1.601

10 pcs: $1.335

45 pcs: $1.121

135 pcs: $0.961

270 pcs: $0.854

540 pcs: $0.774

1035 pcs: $0.71

2520 pcs: $0.681

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$1.601

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of HCPL-314J-000E

Part Number	HCPL-314J-000E	Manufacturer	Avago Technologies (Broadcom Limited)
Description	OPTOISO 5KV 2CH GATE DRIVER 16SO	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	57708 pcs	Data sheet	HCPL-314J-000E.pdf
Voltage - Supply	10 V ~ 30 V	Voltage - Isolation	5000Vrms
Voltage - Forward (Vf) (Typ)	1.5V	Technology	Optical Coupling
Supplier Device Package	16-SO	Series	-
Rise / Fall Time (Typ)	50ns, 50ns	Pulse Width Distortion (Max)	-
Propagation Delay tpLH / tpHL (Max)	700ns, 700ns	Packaging	Tube
Package / Case	16-SOIC (0.295", 7.50mm Width)	Other Names	516-1477-5 HCPL314J000E
Operating Temperature	-40°C ~ 100°C	Number of Channels	2
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	12 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Detailed Description	600mA Gate Driver Optical Coupling 5000Vrms 2 Channel 16-SO	Current - Peak Output	600mA
Current - Output High, Low	500mA, -	Current - DC Forward (If) (Max)	25mA
Common Mode Transient Immunity (Min)	25kV/µs	Approvals	CSA, IEC/EN/DIN, UR
