AMI Semiconductor / ON Semiconductor
| Part Number | NVD6495NLT4G-VF01 | Manufacturer | AMI Semiconductor / ON Semiconductor |
|---|---|---|---|
| Description | MOSFET N-CH 100V 25A DPAK | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 122575 pcs | Data sheet | NVD6495NLT4G-VF01.pdf |
| Vgs(th) (Max) @ Id | 2V @ 250µA | Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) | Supplier Device Package | DPAK |
| Series | - | Rds On (Max) @ Id, Vgs | 50 mOhm @ 10A, 10V |
| Power Dissipation (Max) | 83W (Tc) | Packaging | Tape & Reel (TR) |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 | Other Names | NVD6495NLT4G NVD6495NLT4G-ND NVD6495NLT4G-VF01-ND NVD6495NLT4G-VF01OSTR |
| Operating Temperature | -55°C ~ 175°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 11 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 1024pF @ 25V |
| Gate Charge (Qg) (Max) @ Vgs | 35nC @ 10V | FET Type | N-Channel |
| FET Feature | - | Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Drain to Source Voltage (Vdss) | 100V | Detailed Description | N-Channel 100V 25A (Tc) 83W (Tc) Surface Mount DPAK |
| Current - Continuous Drain (Id) @ 25°C | 25A (Tc) |
