ADI (Analog Devices, Inc.)
| Part Number | ADM7160ACPZN1.8-R2 | Manufacturer | ADI (Analog Devices, Inc.) |
|---|---|---|---|
| Description | IC REG LINEAR 1.8V 200MA 6LFCSP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 80991 pcs | Data sheet | ADM7160ACPZN1.8-R2.pdf |
| Voltage Dropout (Max) | 0.23V @ 200mA | Voltage - Output (Min/Fixed) | 1.8V |
| Voltage - Output (Max) | - | Voltage - Input (Max) | 5.5V |
| Supplier Device Package | 6-LFCSP-UD (2x2) | Series | - |
| Protection Features | Over Temperature, Short Circuit, Under Voltage Lockout (UVLO) | Packaging | Tape & Reel (TR) |
| Package / Case | 6-UDFN Exposed Pad, CSP | PSRR | 54dB ~ 43dB (100kHz ~ 1MHz) |
| Output Type | Fixed | Output Configuration | Positive |
| Other Names | ADM7160ACPZN1.8-R2TR | Operating Temperature | -40°C ~ 125°C (TA) |
| Number of Regulators | 1 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | Manufacturer Standard Lead Time | 7 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Detailed Description | Linear Voltage Regulator IC Positive Fixed 1 Output 1.8V 200mA 6-LFCSP-UD (2x2) |
| Current - Supply (Max) | 350µA | Current - Quiescent (Iq) | 20µA |
| Current - Output | 200mA | Control Features | Enable |
| Base Part Number | ADM7160 |
