Triad Magnetics
| Part Number | TY-146P | Manufacturer | Triad Magnetics |
|---|---|---|---|
| Description | TRANSF 600 AUDIO CT 150/600CT 15 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 18411 pcs | Data sheet | TY-146P.pdf |
| Weight | 0.188 lb (85.28g) | Voltage - Isolation | 1500V |
| Turns Ratio - Primary:Secondary | 1:1 | Transformer Type | Data/Voice Coupling |
| Termination Style | PC Pin | Size / Dimension | 1.375" L x 1.187" W (34.93mm x 30.15mm) |
| Series | TY | Return Loss | 26dB |
| Power Level | 1W | Packaging | Bulk |
| Other Names | 10613 237-1122 TY146P |
Operating Temperature | 0°C ~ 105°C |
| Mounting Type | Through Hole | Manufacturer Standard Lead Time | 32 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | 1.5dB |
| Impedance - Secondary (Ohms) | 600, 150/150 | Impedance - Primary (Ohms) | 600, 150/150 |
| Height - Seated (Max) | 1.187" (30.15mm) | Frequency Response | ±2dB |
| Frequency Range | 200Hz ~ 15kHz | DC Resistance (DCR) - Secondary | 14.5 Ohm, 22 Ohm |
| DC Resistance (DCR) - Primary | 17 Ohm, 19 Ohm | Approvals | - |
