Semtech
| Part Number | ECLAMP2394P.TCT | Manufacturer | Semtech |
|---|---|---|---|
| Description | FILTER LC(PI) 19NH/12PF ESD SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 128346 pcs | Data sheet | ECLAMP2394P.TCT.pdf |
| Voltage - Rated | - | Values | L = 19nH, C = 12pF |
| Type | Low Pass | Technology | LC (Pi) |
| Size / Dimension | 0.083" L x 0.063" W (2.10mm x 1.60mm) | Series | EMIClamp® |
| Resistance - Channel (Ohms) | 18 | Packaging | Original-Reel® |
| Package / Case | 8-UFDFN Exposed Pad | Other Names | ECLAMP2394P.TCTDKR ECLAMP2394P.TCTDKR-ND ECLAMP2394PTCTDKR |
| Operating Temperature | -40°C ~ 85°C | Number of Channels | 4 |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 6 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Height | 0.026" (0.65mm) | Filter Order | 5th |
| ESD Protection | Yes | Detailed Description | LC (Pi) EMI Filter 5th Order Low Pass 4 Channel L = 19nH, C = 12pF 8-UFDFN Exposed Pad |
| Center / Cutoff Frequency | 150MHz (Cutoff) | Attenuation Value | 30dB @ 800MHz ~ 2.7GHz |
| Applications | Data Lines for Mobile Devices |
