LNJ236W82RA

Panasonic

Image may be representation. See specifications for product details.

Product Overview

Part Number:	LNJ236W82RA
Manufacturer/Brand:	Panasonic
Product description	LED RED ESS TYPE LED SMD
Datasheets:	LNJ236W82RA.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	4550 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 4550 pcs

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of LNJ236W82RA

Part Number	LNJ236W82RA	Manufacturer	Panasonic
Description	LED RED ESS TYPE LED SMD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	4550 pcs	Data sheet	LNJ236W82RA.pdf
Wavelength - Peak	645nm	Wavelength - Dominant	630nm
Voltage - Forward (Vf) (Typ)	1.95V	Viewing Angle	-
Supplier Device Package	ESS Type LED	Size / Dimension	1.60mm L x 0.80mm W
Series	-	Packaging	Cut Tape (CT)
Package / Case	0603 (1608 Metric)	Other Names	P14158CT
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	3 (168 Hours)
Millicandela Rating	7mcd	Lens Transparency	-
Lens Style/Size	Rectangle with Flat Top, 1.60mm x 0.80mm	Lens Color	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Height (Max)	0.25mm
Features	-	Detailed Description	Red 630nm LED Indication - Discrete 1.95V 0603 (1608 Metric)
Current - Test	5mA	Configuration	Standard
Color	Red	Base Part Number	LNJ*36
