HomeProductsOptoelectronicsLED Indication - DiscreteLR QH9F-P2R1-1

LR QH9F-P2R1-1

OSRAM Opto Semiconductors, Inc.OSRAM Opto Semiconductors, Inc.
LR QH9F-P2R1-1 Image
Image may be representation. See specifications for product details.

Product Overview

Part Number: LR QH9F-P2R1-1
Manufacturer/Brand: OSRAM Opto Semiconductors, Inc.
Product description LED RED DIFFUSED SMD
Datasheets: LR QH9F-P2R1-1.pdf
RoHs Status Lead free / RoHS Compliant
Stock Condition 5135 pcs stock
Ship From Hong Kong
Shipment Way DHL/Fedex/TNT/UPS/EMS
In Stock 5135 pcs
Request Quote
Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]
  • Target Price:(USD)
  • Qty:

Please give us your target price if quantities greater than those displayed.

  • Part Number
  • Company Name
  • Contact Name
  • E-mail
  • Message

Specifications of LR QH9F-P2R1-1

Part Number LR QH9F-P2R1-1 Manufacturer OSRAM Opto Semiconductors, Inc.
Description LED RED DIFFUSED SMD Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 5135 pcs Data sheet LR QH9F-P2R1-1.pdf
Wavelength - Peak 632nm Wavelength - Dominant 625nm
Voltage - Forward (Vf) (Typ) 2.2V Viewing Angle 120°, 130°
Size / Dimension 1.00mm L x 0.50mm W Series CHIPLED 0402
Packaging Tape & Reel (TR) Package / Case 0402 (1005 Metric)
Other Names LR QH9F-P2R1-1-ND
LRQH9F-P2R1-1
Q65110A8031		 Mounting Type Surface Mount
Moisture Sensitivity Level (MSL) 2 (1 Year) Millicandela Rating 98mcd
Lens Transparency Diffused Lens Style/Size Rectangle with Flat Top, 1.00mm x 0.50mm
Lens Color White Lead Free Status / RoHS Status Lead free / RoHS Compliant
Height (Max) 0.40mm Features -
Detailed Description Red 625nm LED Indication - Discrete 2.2V 0402 (1005 Metric) Current - Test 5mA
Configuration Standard Color Red
