Micrel / Microchip Technology
| Part Number | 2N7002-G | Manufacturer | Micrel / Microchip Technology |
|---|---|---|---|
| Description | MOSFET N-CH 60V 0.115A SOT23-3 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 169924 pcs | Data sheet | 2N7002-G.pdf |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA | Vgs (Max) | ±30V |
| Technology | MOSFET (Metal Oxide) | Supplier Device Package | SOT-23 (TO-236AB) |
| Series | - | Rds On (Max) @ Id, Vgs | 7.5 Ohm @ 500mA, 10V |
| Power Dissipation (Max) | 360mW (Ta) | Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 | Other Names | 2N7002-GMC 2N7002-GMC-ND 2N7002-GMCTR |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 14 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Input Capacitance (Ciss) (Max) @ Vds | 50pF @ 25V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 5V, 10V | Drain to Source Voltage (Vdss) | 60V |
| Detailed Description | N-Channel 60V 115mA (Tj) 360mW (Ta) Surface Mount SOT-23 (TO-236AB) | Current - Continuous Drain (Id) @ 25°C | 115mA (Tj) |
