International Rectifier (Infineon Technologies)
| Part Number | 98-0036 | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | IC DRIVER BRIDGE 3-PHASE 44-PLCC | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 5282 pcs | Data sheet | 98-0036.pdf |
| Voltage - Supply | 10 V ~ 20 V | Supplier Device Package | 44-PLCC, 32 Leads (16.58x16.58) |
| Series | - | Rise / Fall Time (Typ) | 80ns, 35ns |
| Packaging | Tube | Package / Case | 44-LCC (J-Lead), 32 Leads |
| Other Names | *IR2132J IR2132J IR2132J-ND SP001536642 |
Operating Temperature | -40°C ~ 150°C (TJ) |
| Number of Drivers | 6 | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Logic Voltage - VIL, VIH | 0.8V, 2.2V |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Input Type | Inverting |
| High Side Voltage - Max (Bootstrap) | 600V | Gate Type | IGBT, N-Channel MOSFET |
| Driven Configuration | Half-Bridge | Detailed Description | Half-Bridge Gate Driver IC Inverting 44-PLCC, 32 Leads (16.58x16.58) |
| Current - Peak Output (Source, Sink) | 250mA, 500mA | Channel Type | 3-Phase |
| Base Part Number | IR2132J |
