Hammond Manufacturing
| Part Number | 146K | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER AUDIO 1KCT/8 IMPED | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6471 pcs | Data sheet | 146K.pdf |
| Weight | 0.031 lb (14.06g) | Voltage - Isolation | - |
| Turns Ratio - Primary:Secondary | - | Transformer Type | Economical Open Type |
| Termination Style | Wire Leads | Size / Dimension | 1.630" L x 0.880" W (41.40mm x 22.35mm) |
| Series | 146 | Return Loss | - |
| Power Level | 700mW | Packaging | Bulk |
| Other Names | 146KHM 146KHM-ND HM3252 |
Operating Temperature | - |
| Mounting Type | Chassis Mount | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Impedance - Secondary (Ohms) | 8 | Impedance - Primary (Ohms) | 1kCT |
| Height - Seated (Max) | 0.810" (20.57mm) | Frequency Response | ±1dB |
| Frequency Range | 150Hz ~ 15kHz | DC Resistance (DCR) - Secondary | 700 mOhm |
| DC Resistance (DCR) - Primary | 56 Ohm | Approvals | - |
