Hammond Manufacturing
| Part Number | 107X | Manufacturer | Hammond Manufacturing |
|---|---|---|---|
| Description | TRANSFORMER AUDIO 100KCT/1KCT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5757 pcs | Data sheet | 1.107X.pdf2.107X.pdf |
| Weight | 0.02 lb (9.07g) | Voltage - Isolation | 500Vrms |
| Turns Ratio - Primary:Secondary | 10:1 | Transformer Type | Miniature Epoxy Potted |
| Termination Style | PC Pin | Size / Dimension | 0.630" L x 0.586" W (16.00mm x 14.88mm) |
| Series | 107 | Return Loss | - |
| Power Level | 150mW | Packaging | Bulk |
| Other Names | 107XHM 107XHM-ND HM2379 |
Operating Temperature | - |
| Mounting Type | Through Hole | Manufacturer Standard Lead Time | 4 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insertion Loss | - |
| Impedance - Secondary (Ohms) | 1kCT | Impedance - Primary (Ohms) | 100kCT |
| Height - Seated (Max) | 0.630" (16.00mm) | Frequency Response | ±1.5dB |
| Frequency Range | 300Hz ~ 50kHz | DC Resistance (DCR) - Secondary | 75 Ohm |
| DC Resistance (DCR) - Primary | 3.66 kOhm | Approvals | - |
