CUI, Inc.
| Part Number | VESD2-S5-D12-SIP | Manufacturer | CUI, Inc. |
|---|---|---|---|
| Description | DC DC CONVERTER +/-12V 2W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4578 pcs | Data sheet | VESD2-S5-D12-SIP.pdf |
| Voltage - Output 3 | - | Voltage - Output 2 | -12V |
| Voltage - Output 1 | 12V | Voltage - Isolation | 3kV |
| Voltage - Input (Min) | 4.5V | Voltage - Input (Max) | 5.5V |
| Type | Isolated Module | Size / Dimension | 0.77" L x 0.28" W x 0.39" H (19.6mm x 7.0mm x 10.0mm) |
| Series | VESD2-SIP | Power (Watts) | 2W |
| Packaging | Tube | Package / Case | 7-SIP Module, 5 Leads |
| Other Names | 102-2105 656-90203R VESD2-S5-D12-SIP-ND VESD2S5D12SIP |
Operating Temperature | -40°C ~ 85°C |
| Number of Outputs | 2 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | SCP | Efficiency | 85% |
| Detailed Description | Isolated Module DC DC Converter 2 Output 12V -12V 83mA, 83mA 4.5V - 5.5V Input | Current - Output (Max) | 83mA, 83mA |
| Applications | ITE (Commercial) |
