Bourns, Inc.
| Part Number | SDR1806-1R0ML | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 1UH 10A 4 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 140018 pcs | Data sheet | SDR1806-1R0ML.pdf |
| Type | Wirewound | Tolerance | ±20% |
| Supplier Device Package | - | Size / Dimension | 0.720" L x 0.551" W (18.30mm x 14.00mm) |
| Shielding | Unshielded | Series | SDR1806 |
| Ratings | - | Q @ Freq | 21 @ 7.96MHz |
| Packaging | Tape & Reel (TR) | Package / Case | Nonstandard |
| Other Names | SDR1806-1R0ML-ND SDR1806-1R0MLTR SDR18061R0ML |
Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Core | Ferrite | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 100kHz |
| Inductance | 1µH | Height - Seated (Max) | 0.272" (6.90mm) |
| Frequency - Self Resonant | 100MHz | Detailed Description | 1µH Unshielded Wirewound Inductor 10A 4 mOhm Max Nonstandard |
| DC Resistance (DCR) | 4 mOhm Max | Current Rating | 10A |
| Current - Saturation | 30A |
