Avago Technologies (Broadcom Limited)
| Part Number | HCPL-2201-000E | Manufacturer | Avago Technologies (Broadcom Limited) |
|---|---|---|---|
| Description | OPTOISO 3.75KV PUSH PULL 8DIP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 78450 pcs | Data sheet | HCPL-2201-000E.pdf |
| Voltage - Supply | 4.5 V ~ 20 V | Voltage - Isolation | 3750Vrms |
| Voltage - Forward (Vf) (Typ) | 1.5V | Supplier Device Package | 8-DIP |
| Series | - | Rise / Fall Time (Typ) | 30ns, 7ns |
| Propagation Delay tpLH / tpHL (Max) | 300ns, 300ns | Packaging | Tube |
| Package / Case | 8-DIP (0.300", 7.62mm) | Output Type | Push-Pull, Totem Pole |
| Other Names | 516-1649-5 HCPL2201000E |
Operating Temperature | -40°C ~ 85°C |
| Number of Channels | 1 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 8 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inputs - Side 1/Side 2 | 1/0 |
| Input Type | DC | Detailed Description | Logic Output Optoisolator 5MBd Push-Pull, Totem Pole 3750Vrms 1 Channel 1kV/µs CMTI 8-DIP |
| Data Rate | 5MBd | Current - Output / Channel | 25mA |
| Current - DC Forward (If) (Max) | 10mA | Common Mode Transient Immunity (Min) | 1kV/µs |
