Panasonic
| Part Number | EEE-FT1E101AP | Manufacturer | Panasonic |
|---|---|---|---|
| Description | CAP ALUM 100UF 20% 25V SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 488667 pcs | Data sheet | 1.EEE-FT1E101AP.pdf2.EEE-FT1E101AP.pdf3.EEE-FT1E101AP.pdf4.EEE-FT1E101AP.pdf5.EEE-FT1E101AP.pdf |
| Voltage - Rated | 25V | Tolerance | ±20% |
| Surface Mount Land Size | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Size / Dimension | 0.248" Dia (6.30mm) |
| Series | FT | Ripple Current @ Low Frequency | 195mA @ 120Hz |
| Ripple Current @ High Frequency | 300mA @ 100kHz | Ratings | AEC-Q200 |
| Polarization | Polar | Packaging | Tape & Reel (TR) |
| Package / Case | Radial, Can - SMD | Other Names | EEEFT1E101AP PCE5007TR |
| Operating Temperature | -55°C ~ 105°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 19 Weeks |
| Lifetime @ Temp. | 2000 Hrs @ 105°C | Lead Spacing | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 0.240" (6.10mm) |
| ESR (Equivalent Series Resistance) | 260 mOhm @ 100kHz | Detailed Description | 100µF 25V Aluminum Electrolytic Capacitors Radial, Can - SMD 260 mOhm @ 100kHz 2000 Hrs @ 105°C |
| Capacitance | 100µF | Applications | Automotive |
