NJG1544HC3-TE1#

JRC Corporation / NJRC

Image may be representation. See specifications for product details.

Product Overview

Part Number:	NJG1544HC3-TE1#
Manufacturer/Brand:	JRC Corporation / NJRC
Product description	IC MMIC SWITCH ANTENNA 2X2 10USB
Datasheets:	NJG1544HC3-TE1#.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	67563 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 67563 pcs

Reference Price (In US Dollars)

3000 pcs: $0.331

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.331

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of NJG1544HC3-TE1#

Part Number	NJG1544HC3-TE1#	Manufacturer	JRC Corporation / NJRC
Description	IC MMIC SWITCH ANTENNA 2X2 10USB	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	67563 pcs	Data sheet	NJG1544HC3-TE1#.pdf
Voltage - Supply	2.5 V ~ 5.5 V	Topology	Reflective
Test Frequency	2.5GHz	Supplier Device Package	10-USB-C3 (2x1.5)
Series	-	RF Type	802.11b/g
Packaging	Tape & Reel (TR)	Package / Case	10-WFDFN Exposed Pad
P1dB	28dBm	Other Names	NJG#1544HC3-TE1 NJG#1544HC3-TE1-ND
Operating Temperature	-40°C ~ 85°C	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Manufacturer Standard Lead Time	12 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Isolation	23dB	Insertion Loss	0.5dB
Impedance	50 Ohm	IIP3	-
Frequency Range	DC ~ 2.5GHz	Features	-
Detailed Description	RF Switch IC 802.11b/g SPDT 2.5GHz 50 Ohm 10-USB-C3 (2x1.5)	Circuit	SPDT
